CADprofi Mechanical

파라메트릭 기반 CAD-응용프로그램은 기계 설계 및 엔지니어링 프로젝트를 쉽게 할 수 있습니다. Mechanical 모듈은 지역 및 국제 표준을 기반으로 표준화된 강제창호, 기타 철강제품 등 광범위한 데이터를 갖추고 있습니다. 이 라이브러리는 열 교환기 및 기타장치 설계에 사용되는 볼트, 나사, 와셔, 너트, 조인트, 리벳, 스터드, L-바, 테이퍼 채널 바 등 수많은 부품이 포함되어 있습니다. 뛰어난 다이어그램과 청사진 편집기는 배관 및 공압 설비의 도면작성을 편리하게 합니다.

CADprofi Mechanical module can be bought separately or in full CADprofi Suite package, which contains all 4 CADprofi modules for 50% of the price.

주요 특징들:

자세한 내용을 보려면 기능을 클릭하세요

Standardized parts

A rich set of parametric standardized parts and fasteners prepared on the basis of national and international standards (e.g. ISO, ANSI, ASME, EN, DIN, PN, IS, JIS, GOST), including bolts, screws, washers, nuts, joints, rivets, studs, openings, rebates, wedges, pivots, pins, bearings, grease nipples, rings and many more.

Shapes and profiles

Steel and aluminium shapes and profiles: L-shapes, C-shapes, T-shapes, flat bars, hollow profiles, rods, pipes and others. In profiles, it is possible to specify the material type (type of steel).

Designing apparatus

Elements used for designing apparatus, including flanges and dished ends, steel pipes and fittings (elbows, tees, reducers). It is possible to draw pipelines with automatic insertion of bends and automatic connection of pipes by using a variety of fittings.

Heat exchangers

Procedures used for calculating the heat exchangers and different types of tube bundles in heat exchangers.

Dynamic scaling

Dynamic scaling of parts when inserting them into drawing or when editing projects. This allows for automatic selection of the size of the element directly in the drawing (e.g. selecting screws with a length matched to the thickness of connected elements).

Different views

All parts have different views adapted for creating different designs (e.g. front views, side, cross-section etc.). It is also possible to define the style and detail level that allows for insertion of parts with details, axes, hatch etc.

Marks

System of freely configurable marking welds, tolerance signs, edge, roughness and others. Inserting weld views (V welds, fillet welds) with the possibility of defining user own dimensions.

Pneumatic systems

Convenient design of diagrams and pneumatic systems using smart symbols, lines and editing functions.

Drawing tools

Additional drawing tools that greatly facilitate the creation of technical drawings (axis, circle axes, center marks, bisectors and others). Function of detecting all circles in the selected block and automatic insertion of circle axes or center marks in them.

Read more about other CADprofi Mechanical key features

Versatile editing commands that allow for elements mirroring, extending steel profiles etc.
Designing is done in accordance with designers habits and requirements.
Metric or imperial units available.
Tools for full description and projects detailing.
Automatic numbering of objects.
A system of quick search of products in the database.
Possibility to filter objects, e.g. by dimensions or names. Filter can be applied to the entire library, making it much easier to select various elements needed to design a given component - for example, the selection of bolts, washers and nuts with a specific diameter.
Access to CAD libraries of many world known manufacturers.
Possibility to import and add to the program user's own symbols or objects.
Automatic layer management and printing styles allows user to achieve prints with predefined line thickness, colours, etc.
Possibility to define the list of "favourites" that allows to work in accordance with user habits and preferences.
Compression and disc springs.

Possibility of adding your own translations or changing the terminology that is used in the program.
Smart insertion of objects with the possibility of attaching them to other objects by using the "one-click" technology.
Intelligent commands that allow for performing quick editing operations on symbols and objects directly in the drawing.
The Quick edit (QED) command that allows user to perform basic editing operations on symbols and objects, including edit, attributes and descriptions, mirror, scale, copy, rotate, delete, move, insert alternative view.
Possibility to create any diagrams, flowcharts, technological and functional schemes, algorithms.
Possibility to create bill of materials and specifications that can be either printed or exported to multiple formats including pdf, rtf (doc), xls, xml, csv, html and more.
Automatic creation of graphical legends.
On-line help with many illustrations and exemplary videos that explain in details how to use the program.
On-line update system.

Versatile editing commands that allow for elements mirroring, extending steel profiles etc.
Designing is done in accordance with designers habits and requirements.
Metric or imperial units available.
Tools for full description and projects detailing.
Automatic numbering of objects.
A system of quick search of products in the database.
Possibility to filter objects, e.g. by dimensions or names. Filter can be applied to the entire library, making it much easier to select various elements needed to design a given component - for example, the selection of bolts, washers and nuts with a specific diameter.
Access to CAD libraries of many world known manufacturers.
Possibility to import and add to the program user's own symbols or objects.
Automatic layer management and printing styles allows user to achieve prints with predefined line thickness, colours, etc.
Possibility to define the list of "favourites" that allows to work in accordance with user habits and preferences.
Compression and disc springs.
Possibility of adding your own translations or changing the terminology that is used in the program.
Smart insertion of objects with the possibility of attaching them to other objects by using the "one-click" technology.
Intelligent commands that allow for performing quick editing operations on symbols and objects directly in the drawing.
The Quick edit (QED) command that allows user to perform basic editing operations on symbols and objects, including edit, attributes and descriptions, mirror, scale, copy, rotate, delete, move, insert alternative view.
Possibility to create any diagrams, flowcharts, technological and functional schemes, algorithms.
Possibility to create bill of materials and specifications that can be either printed or exported to multiple formats including pdf, rtf (doc), xls, xml, csv, html and more.
Automatic creation of graphical legends.
On-line help with many illustrations and exemplary videos that explain in details how to use the program.
On-line update system.
